Curtain Switch Module

WiFi DIY RF433 Smart Curtain Switch Module for Electric Motorized Roller Blinds Shutter Motor,Smart Life/Tuya APP RF433 Remote Control,Compatible with Alexa Echo and Google Home

by Moes

Main Features:

• Use with Much More Convenience:A really good substitution for one more new smart roller blindsswitch to work with your traditional curtain switch to realize intelligence.Also,it can be connected with your roller blinds shutter motor to smartly control your curtains.
• RFand Wireless Remote Control:Enable to remotely control your connected appliances on your smart phone wherever you are. 2.4 b/g/n Networks provides the needed connection to the DIY Switch Module without the need of a separate HUB.(Compatible with Android&iOS.)More importantly,this curtain switch module is built-in RF433 frequency,so it can be controlled with remote control switch with encoding 1527.
• Hands-free Voice Control:Compatible with Amazon Alexa and Google Home for easy voice control,providing your smart life for controlling roller blinds with much more convenience.
• Timer Setting:Take full control of your roller blindsintelligently with the timer feature on your App,which enables to open / close them at a specific time automatically. Automate your home roller blinds via 3 timing types:schedules timing,countdown timing and loop timing.
• Family Sharing:One device can be shared to different family members that means one ID is able to control multiple curtains,or multiple users can control one curtain.Control your smart home with your family members or friends together.

Note before order：

1. Please check your motor is with 4 wires before make your order.(Note:Motor not included,need a separate purchase.)
2. This roller blinds shutterswitch module can not work with DC motor.
3. Please use this module with RF433 remote control switch（only encoding 1527 required.）

Parameter:

Product type: WiFi Curtain Module

Voltage: 90-250V AC 50/60Hz

Current: 2A

Power Load:500W(Max.)

WiFi frequency: 2.4GHz-2.4835GHz WiFi

RF frequency:433MHz,encoding 1527

Operation temp: -10℃-+40℃

Case temp: Tc +80℃(Max.)

Operation range:≤200m

Dims(W*D*H): 52*47*18mm(without clip)

IP rating: IP20

Warranty: 1year

Package Listing:

WiFi Curtain Module*1(with mounting clip)

Instruction Manual*1

Remote Control Switch*1

Note:Motor not included,need a separate purchase.

User Manual:

https://drive.google.com/file/d/1zOUgFSv3Z98Gc9Reifzr6DmUSl7EZQ8Z/view?usp=sharing

WiFi Mini DIY Smart Curtain Switch Module for Electric Motorized Roller Blinds Shutter Motor,Smart Life/Tuya APP Remote Control,Compatible with Alexa Echo and Google Home

by Moes

Main Features:

• Use with Much More Convenience with stop function on traditional switch:A really good substitution for one more new smart roller blindsswitch to work with your traditional curtain switch to realize intelligence.Press your traditional curtain switch once after switch to up/down (on the same button)to manually stop your curtains easily.Also,it can be connected with your roller blinds shutter motor to smartly control your curtains.
• RFand Wireless Remote Control with a much easier pairing mode for adding the device with WiFi and Bluetooth connected:Enable to remotely control your connected appliances on your smart phone wherever you are. 4 b/g/n Networks provides the needed connection to the DIY Switch Module without the need of a separate HUB.(Compatible with Android&iOS for Smart Life and Tuya App.)More importantly,this curtain switch module is built-in RF433 frequency,so it can be controlled with remote control switch with encoding 1527.
• Hands-free Voice Control:Compatible with Amazon Alexa and Google Home for easy voice control,providing your smart life for controlling curtains with much more convenience.
• Timer Setting:Take full control of your roller blinds intelligently with the timer feature on your App,which enables to open / close them at a specific time automatically. Automate your home curtains via 3 timing types:schedules timing,countdown timing and loop timing.
• Family Sharing:One device can be shared to different family members that means one ID is able to control multiple curtains,or multiple users can control one curtain.Control your smart home with your family members or friends together.

Note before order：

1. Please check your motor is with 4 wires before make your order(Note:Motor not included,need a separate purchase.)
2. This roller blinds switch module can not work with DC motor.
3. This switch module is a Wi-Fi version only,not with RF,so it can not work with the RF remote in our store.

Parameter:

Product type: WiFi Curtain Module

Voltage: 90-250V AC 50/60Hz

Current: 2A

Power Load:500W (Max.)

WiFi frequency: 2.4GHz WiFi

Operation temp: -10℃-+40℃

Case temp: Tc +80℃(Max.)

Operation range:≤200m

Dims(W*D*H): 52*47*18mm(without clip)

IP rating: IP20

Warranty:1year

Package Listing:

WiFi Curtain Module*1(with mounting clip)

Instruction Manual*1

Note:Motor not included,need a separate purchase.

User Manual:

https://drive.google.com/file/d/1zOUgFSv3Z98Gc9Reifzr6DmUSl7EZQ8Z/view?usp=sharing

Q&A:

1. Q:Does this work with Google Home?

  A:Yes,it does.And it’s also compatible with Alexa.

2. Q:Do I need to buy a hub to work with the curtain module.

  A:No,there is no need for you to buy a hub and no hub required for the module.

3. Q:Can I control the module with my own remote control switch?

  A:This type of curtain switch module is no RF433 built in,so it can not work with RF433 remote control switch in our store.

4. Q:Shall I buy a smart curtain switch to work with this module?

   A:No,you can just connect the module to your traditional curtain switch to realize intelligence.

5. Q:What should I do if I can’t configure the curtain module?

A:a:Please check whether device is powered on.

b:Make sure your mobile and curtain module are under the same 2.4GHz wifi network.

c:Whether it’s in good internet conditions.

d:Make sure the password entered in App is correct.

e:Make sure the wiring is correct.

6. Q:Which products can I control with the device?

   A:Curtains,shutter,blind....

7. Q:What happens if the wifi goes off?

   A:You can still control the device connected to the curtain module with your traditional curtain switch and once wifi is active again the device connected to the curtain module will connect automatically to your wifi network.

8. Q:What should I do if I change the wifi network or change the password?

   A:You can connect the module to the wifi network according to the App User Manual.

Yet2169-s28 is a remote control for transmitting RF signal with a frequency of 433.92MHz and modulation mode of OOK.This product has a display window of 8-segment digital tube, which can display a total of 9 channels from 0 to 8. Different channels can be freely switched by pressing the button, and different actions can be performed when the receiver receives different code values.Two versions available with single channel and 9 channels.Use this remote with our Moes curtain switch and curtain switch module only,no other devices available.

by Moes

Main Features:

1. 9 Channel RF433 frequency remote is designed for separately controlling our curtain switch and curtain switch module in a much easier way with its maximum controllable quantity of nine;easily achieve another control to the whole house curtains without interference after successfully paired,especially suitable for the old.
2. Extremely simple matching way supported for simple use.You need to pair the three button(up,down,stop)one by one to the curtain switch or switch module for correct control.With the new added set button for  easychannel settings.
3. Encoding 1527 required for the remote.No other codes available for this curtain control system,highly recommend to use this special remote for controlling our Moes curtain switch or switch module.Do not use this remote to control other irrelevant devices,only our Moes curtain switch and switch module availabe.
4. Battery powered:23A*12V battery required for this remote with long time standby.(Battery not included in the package restricted by the shipping)
5. Includes full 2-year warranty and 60-day refund guarantee for complete satisfaction.

Note:9 Channel can only be used with our Moes Curtain switch and curtain switch module;Choose the right version for your own need before placing your order.

User Manual:

https://drive.google.com/file/d/1j7slXOvSBlCZeXx8i_0UqvoUMuV3xQQK/view?usp=sharing
